Custom Pressure Range:

Senphire (as well as many other leading manufacturers) specify accuracy in terms of % Full Scale (%FS). Full scale refers the the full pressure scale the sensor is calibrated to. To ensure you are getting the maximum accuracy your sensor needs to be optimized to the exact pressure range you are trying to measure. For example using a 15 psi FS sensor to measure 7.5 psi FS would result in half accuracy than using a 7.5 psi FS sensor.

Custom Outputs:

This corresponds to the analog voltage levels the sensor is calibrated to. The standard output for a 5 psi sensor is 0.5V to 4.5V at offset (0 psi) and full scale (5 psi) respectively. What if you are using an alternate part which is calibrated to 0.2V and 4.7V? No problem we can accommodate this in our calibration. We can even invert the polarity such that 0.5V at 5 psi and 4.5V at 0 psi.

Custom Pressure Die:

Do you need to use a special pressure die? For example a low pressure sensor with extra high over pressure? Extra high sensitivity pressure die? We can source and package a suitable solution for you.

Note: Request will be considered on a case by case basis. Minimum orders apply. Please contact us for more details.
